Y-Type Angle Valve
- Size : 15 NB – 50 NB (1/2″ – 2″)
- Type : 2-Way
- Pressure Rating : PN16 upto 40 mm (1.5″)
PN7 for 50 mm (2″) - Operating Temp. : upto 180 deg C
- Process Connection : Screwed End / Flanged End / Tri-Clover (TC)
- Leakage Class : Tight Shut-OFF
- Body MoC : SS304 / SS316 / SS 316L
- Plug MoC : SS304 / SS316 / SS 316L
- Duty : ON-OFF
- Pneumatic Pressure : 4-6 Barg
- Signal : ON/OFF – 220VAC / 24VDC
ON/OFF – 24VDC
DESCRIPTION
- Reliable & Cost Effective
- Best Quality
- Light in weight
- Asthetically designed
- Tested for more than 10 Million Cycle
- Comparatively Longer life
- Large size indicator provides better position indication from a distance
- Lowest delivery period
SPECIFICATIONS
- Size : 15mm to 50mm (1/2″ to 2″)
- Type : 2-Way
- Body : SS304 / SS316 / SS 316L
- Plug : SS304 / SS316 / SS 316L
- Seat : PTFE
- Pressure Rating : PN16 upto 40 mm (1.5″), PN7 for 50 mm (2″)
- Temperature : upto 180 deg C
- Connection : Screwed End / Flanged End / Tri-Clover (TC)
- Leakage Class : Tight Shut-OFF
- Body : SS304
- Pneumatic Pressure : 4 – 6 Barg
- Air Connection : 1/4″ BSP
- Position Indicator : Mechanical Position indicator
- Environment Temp. : -30° C to +60° C
Application :
HVAC, Power Plant, Water Treatment, Water Management System, Chemical Plant, Sugar Plant, Cement Plant, Utilities, Paper Plant, Distilleries etc.
